Latex Resin

Drying treatment of latex resins has always been a technological challenge in the chemical and materials industry. Traditional drying methods are not only inefficient, but also easy to lead to uneven drying of materials and performance degradation. Jiangsu Bohong for this industry pain point, developed a special horizontal continuous fluidised bed dryer for latex resin, with its innovative working principle and drying effect, for the drying of latex resin provides a new solution.

Ⅰ. the drying principle:
The core working principle of Jiangsu Bohong Horizontal Continuous Fluidised Bed Dryer for Latex Resin is solid fluidisation technology. Through the bottom of the air distribution device will introduce clean air, so that the material in the dryer to form a fluidised state, with full contact with the hot air, so as to complete the drying process in a relatively short period of time. Specifically, after the wet material enters the dryer from the doser, it forms a boiling state under the action of hot air, and the material makes extensive contact with the hot air, which enhances the process of heat and mass transfer and realises efficient drying. This design not only improves the drying efficiency, but also ensures the quality and uniformity of the dried material.

In addition, the equipment adopts a special design of fluidised bed, so that the hot air stream entering the fluidised bed refracts a certain angle with the bed surface, so that the dry materials in boiling can gradually move forward with the movement of the air stream, and finally discharged smoothly. This unique design effectively avoids the accumulation of materials in the drying process and uneven drying phenomenon, ensuring the continuity and stability of the drying process.

Ⅱ. Equipment structure features:
Jiangsu Bo Hong Horizontal Continuous Fluidised Bed Dryer for Latex Resin adopts modular design concept, mainly composed of the following parts:
1. Feeding System
Feeding system adopts screw charging or pneumatic conveying to ensure that the material enters into the drying mainframe uniformly to prevent lumping or piling up.
2. Fluidised bed drying mainframe
Fluidised bed drying mainframe is the core part of the equipment, which adopts modular bed design and supports multi-stage temperature control to enhance drying flexibility. Through the optimised airflow distribution technology, it ensures that the materials always keep fluidised state in the drying process, fully contact with the hot air, and evaporate the moisture quickly.
3. Hot air system
The hot air system includes hot air furnace, air filtration device, blower and heat exchanger, with optional heat sources such as electric heating, steam and heat-conducting oil. Through the high efficient heat exchanger, the hot air system can provide stable hot air flow to ensure that the materials are evenly heated.
4. Gas-solid separation system
The gas-solid separation system consists of a cyclone separator, a pulsed bag filter and a water film dust removal device. The cyclone separator is used to recover the coarse particles, the pulse bag filter further collects the micro-powder, and the water film dust collector is used to purify the exhaust gas to ensure that the gas emission meets the environmental protection standard.
5. Discharge System
The dried materials are discharged through pneumatic conveying or screw conveying, and are directly sent to the finished product storage bin or packaging system.
6. Control System
The control system adopts PLC+HMI touch screen interface, with real-time monitoring functions of temperature, wind speed, bed pressure difference, and equipment running status, so as to realise intelligent control, fault alarm and data recording. This design not only improves the convenience of operation, but also reduces labour costs and operational risks.

Ⅲ. Application Advantages:
Jiangsu Bohong Horizontal Continuous Fluidised Bed Dryer for Latex Resin For the characteristics of latex resin, a number of technological innovations to meet the special needs of latex resin drying:
1. Low temperature drying technology
The equipment adopts low temperature drying technology, through the control of the drying temperature, to ensure that the properties of latex resin in the drying process to be retained, and at the same time to avoid over-drying of the material or agglomeration.
2. Fully enclosed design
The equipment adopts a fully enclosed design, which effectively prevents the leakage of dust and ensures a clean and environmentally friendly working environment. The fully enclosed design not only meets the environmental requirements of modern factories, but also avoids the pollution of the external environment on the material, ensuring the quality of the dried material.
3. Vibration-assisted technology
The design of vibrating fluidised bed combines vibration-assisted technology, which makes the material form a fluidised state in the bed through vibration, and greatly improves the contact area between the material and the hot air as well as the heat transfer efficiency. Vibration assisted technology not only improves the drying efficiency, but also ensures the uniformity of the material in the drying process, avoiding the occurrence of local overheating or agglomeration.
4. Intelligent control system
The equipment is equipped with an advanced intelligent control system, which realises full automatic operation. The operator can easily set and adjust the drying parameters through the control panel to ensure the stability and consistency of the drying process.
5. Energy-saving and environmental protection design
The equipment is designed with full consideration of energy-saving and environmental protection needs. The energy consumption is greatly reduced by the highly efficient heat exchanger and energy-saving motor. At the same time, the fully enclosed design reduces the leakage of hot air, further improves the efficiency of heat energy utilisation and realises energy-saving drying.

Ⅳ. Widely used:
Jiangsu Bohong Horizontal Continuous Fluidised Bed Dryer for Latex Resin is not only suitable for drying latex resin, but also can be widely used for drying other powdery and granular materials, such as polymer resins, crystalline sodium sulphate, chlorinated polypropylene, industrial salts, and boric acid. Whether in the production process of chemical raw materials, or in the field of food processing or pharmaceutical manufacturing, the equipment can meet the strict requirements of different industries for material drying with its high efficiency, energy saving and stable performance, providing users with reliable drying solutions.

Ⅴ.Choose Bohong
Jiangsu Bohong Horizontal Continuous Fluidised Bed Dryer for Latex Resin brings a new drying solution to the chemical and material industry with its innovative working principle, energy efficient drying process and exclusive design for latex resin. Choose Bo Hong, not only choose a high-quality drying equipment, but also choose a kind of improve production efficiency, reduce production costs, ensure product quality and reliable solutions. Jiangsu Bo Hong will continue to be committed to technological innovation and product development, to provide users with more products and services, help enterprises to achieve sustainable development.
